Product Details
Place of Origin: Henan, China
Brand Name: ZENGTUO
Payment & Shipping Terms
Minimum Order Quantity: 2 units
Price: $7,900.00/units 2-9 units
Supply Ability: 5000 Unit/Units per Month
Advantage: |
Eco Friendly, Fast Install,Wind Proof,light Weight, |
Service Life: |
At Least 35 Years |
Structure: |
Q235/Q345 Light Steel Frame |
Applications: |
Office Buildings,hotel,mall,mining Area,etc |
Floor: |
MGO Board,Fiber Cement Board,PVC Board |
Wall: |
Sandwich Panel Wall |
Standard Size: |
5800*2400*2890mm Or Custom Requirement |
Certificate: |
ISO9001-2000,ISO14001 |
Advantage: |
Eco Friendly, Fast Install,Wind Proof,light Weight, |
Service Life: |
At Least 35 Years |
Structure: |
Q235/Q345 Light Steel Frame |
Applications: |
Office Buildings,hotel,mall,mining Area,etc |
Floor: |
MGO Board,Fiber Cement Board,PVC Board |
Wall: |
Sandwich Panel Wall |
Standard Size: |
5800*2400*2890mm Or Custom Requirement |
Certificate: |
ISO9001-2000,ISO14001 |
Anti-rust: all material use hot glavanized steel
Waterproof: without wood ceiling,wall
Fireproof:Fire rating A grade
Simple foundation:just need 12pcs concrete bolck foundation
|
Size
|
Standard size or customized
|
|
Loading
|
1x40HQ can load 1-6 units
|
|
Weight
|
2800 kg/unit
|
|
Floor load
|
250 kg/sqm
|
|
Roof load
|
100 kg/sqm
|
|
Option size
|
20ft,40ft,etc...We also had special size for 2.9M height
|
|
|
|
|
Main material
|
Galvanized steel structure with sandwich panel wall and doors, windows, etc.
|
|
|
|
|
Weight
|
3200kgs
|
|
|
|
|
Service life
|
60-70 years
|
|
|
|
|
Color
|
White, blue, green, brown, or customized
|
|
|
|
|
Columns
|
3mm Hot galvanized steel structure
|
|
|
|
|
Steel structure
|
3mm Hot galvanized steel structure with 4 corner casts and
(1)18mm fiber cement board; (2)1.6mm PVC flooring; (3)50mm rock woll ,eps or PU sandwich panel (4)Galvanized steel base plate. |
|
|
|
|
Wall
|
50/75/100mm EPS/Rock wool/PU Sandwich Panel
|
|
|
|
|
Roof
|
3-4mm Hot galvanized steel structure with 4 corner casts and
(1)Galvanized steel roof covering; (2)50mm -70mm eps sandwich panel or PU sandwich panel ; (3)50mm -70mm eps sandwich panel or PU sandwich panel ; |
|
|
|
|
Door
|
Made of steel/aluminum frameDimension W870*H2040mm, furnish with a handle lock with 3 keys
or sliding glass door W1500*2000mm. |
|
|
|
|
Window
|
Made of PVC/aluminum fame.Dimension W800*H1100mm, glazed with double glass in a thickness of 5/8/5mm.
|
|
|
|
|
Connection kits
|
PVC Connection kits for ceiling, floor and walls.
|
|
|
|
|
Electricity
|
3C/CE/CL/SAA Standard,with distribution box, lights, switch, sockets, etc.
|
|
|
|
