Product Details
Place of Origin: Henan, China
Brand Name: ZENGTUO
Payment & Shipping Terms
Minimum Order Quantity: 500 square meters
Price: $15.00/square meters 500-999 square meters
Supply Ability: 4000 Ton/Tons per Month
Panel Material: |
Metal |
Resistance: |
Temperature From -40°c To +100°c |
Surface Material: |
Color Coated Steel Sheet |
Color: |
Any Color |
Core Material: |
Polyurethane Foam |
Thiskness: |
50-200 Mm |
Shipment Container: |
20ft Container , 40HQ |
Fireproof Grade: |
B1 |
Density: |
35-40kg/m³ |
Application: |
Roof, Wall, Ceiling, Partition |
Panel Material: |
Metal |
Resistance: |
Temperature From -40°c To +100°c |
Surface Material: |
Color Coated Steel Sheet |
Color: |
Any Color |
Core Material: |
Polyurethane Foam |
Thiskness: |
50-200 Mm |
Shipment Container: |
20ft Container , 40HQ |
Fireproof Grade: |
B1 |
Density: |
35-40kg/m³ |
Application: |
Roof, Wall, Ceiling, Partition |
Product introduction
A standard width is 1meters and customizable length
The panel thickness ranges from 50 mm to200mm The facing material thickness is 0.55 mm colorbonded coated steel sheets, including a primer and an Anti-Bacteria Food Grade/Stainless SUS 304 2B coating.
The core comprises FGrade Polyurethane Foam (flame-retardant material with combustible properties). It has a low k-value, indicating good thermal conductivity, and a density of 38 kg – 40 kg per cubic meter (2.50 pounds/cubic feet).
Options of smooth and grooved surfaces, with the grooves spaced every 100 mm, providing high-performing strength
peculiarity
Low thermal conductivity of PU sandwich panels with excellent thermal insulation properties, can greatly reduce the thickness of periphery of the building structure, which effectively increasing the interior area of the building and save energy and costs.
Lightness in weight and Heavy Weight Carier: with respect o weight, pu sandwich panelis versatile.
Simple construction: polyurethane sandwich plate has the characteristics of standardized production and on-site assembly, convenient installation, can improve the construction efficiency.
advantage
Low thermal conductivity polyurethane sandwich plate composite plate has small thermal conductivity, good thermal insulation performance, is the best insulation material.
ECOLOGICAL
100% of the material is recyclable and the panels are friendly to the environment at the production and disposal stages.
Beautiful and economic surface forms are diverse, rich in color, reduce material loss, save construction time and project costs
Sound absorption.
Specifications
|
Panel effective width
|
1000mm |
|
Surface sheets |
Steel sheets(0.40 ~ 0.70 mm)
|
|
Panel thickness
|
50/75/100/150/200/250 mm |
|
Core material density
|
38 ~ 42 KG/M³ |
|
Regular color
|
White grey, Sea blue, White sliver grey |
|
Special color
|
customized |
|
Length limitation |
Max 5.9m for 20FT;
|
|
Max 11.95m for 40FT.
|
|
|
Main application
|
Cold room,food factory,cool room,freezer room,etc. |
