Product Details
Place of Origin: Henan, China
Brand Name: ZENGTUO
Payment & Shipping Terms
Minimum Order Quantity: 500 square meters
Price: $11.90/square meters 500-1999 square meters
Supply Ability: 4000 Ton/Tons per Month
Color: |
White |
Density: |
40kg/m3 |
Material: |
Polyurethane |
Fire Rating: |
Class B1 |
Thermal Conductivity: |
0.022 W/mK |
Width: |
1000mm |
Application: |
Building Insulation |
Water Absorption: |
≤1.5% |
Thickness: |
50-200mm |
Color: |
White |
Density: |
40kg/m3 |
Material: |
Polyurethane |
Fire Rating: |
Class B1 |
Thermal Conductivity: |
0.022 W/mK |
Width: |
1000mm |
Application: |
Building Insulation |
Water Absorption: |
≤1.5% |
Thickness: |
50-200mm |
advantage
Low thermal conductivity polyurethane sandwich plate composite plate has small thermal conductivity, good thermal insulation performance, is the best insulation material.
Good strength parameters. Roof panels can withstand the load of snow and wind depending on their thickness and climatic zone, with supports’ span of more than 3 m. In most cases, wall panels can be used with supports’ span of up to 6 m.This results in real savings in terms of the supporting structure, and thus overall costs of the entire building.
Waterproof, moisture-proof polyurethane sandwich board beautiful appearance, the overall effect is good, it sets load bearing, heat preservation, fire prevention, waterproof in one, and no two decoration,
Fast and convenient installation, short construction period, good comprehensive benefits
peculiarity
Heat and sound insulation. Temperature suitable for PU ranges from -200 centigrade to 150 centigrade.
Good chemical resistance, waterproof, anti-corrosion, insect-free etc.
Advanced Tech: Automatic rolling machines make the whole process of manufacture effective.
High strength: The panels of polyurethane sandwich sheets are usually made of high-strength materials such as steel or aluminum sheets, which make them have high bending and compression resistance
Lightweight: Polyurethane foam has a low density, so the polyurethane sandwich sheet is relatively light, which is conducive to reducing the building's own weight and transportation costs.
Thermal insulation: Polyurethane foam has good thermal insulation properties, which can effectively reduce energy loss and improve the energy efficiency of buildings.
specification
|
Effective width
|
1000(mm) |
| Length | According to customer's request, less than 11.8m. |
| Materials | Polyurethane foam panel,Color steel tile |
|
Structure |
Upper and lower layer: Color steel sheet |
| Middle: Polystyrene foam board | |
| Density | 40-45 kg/m³ |
| Conventional color | White, sea blue, red etc. |
| Life time |
More than 20 Years
|
| Performance | Light weight, heat insulation, water resistant, green and environmental |
| Usage | Roof, Wall, Ceiling, Partition |
