Product Details
Place of Origin: China henanxinxing
Brand Name: Zengtuo
Certification: ISO CE
Model Number: 20ft and customizable
Payment & Shipping Terms
Minimum Order Quantity: 10 set
Payment Terms: T/T
Advantage: |
Anti-slip Waterproof |
Plumbing System: |
Water Pipes, Drainage Pipes, Faucets |
Drawing Design: |
Customer's Requirement |
Edges: |
All Edges Are Sealed By Waterproof Paint |
Material: |
Steel Structure With EPS/PU/Rock Wool Sandwich Panel |
Seismic Performance: |
8 Degree |
Port: |
Qingdao /Tianjing/Shanghai/Gunagzhou |
Transportation: |
Can Be Transported As A Whole Or Disassembled |
Lifespan: |
More Than 15 Years |
After Sales: |
Online Technical Support |
Design: |
Professional Architect Drawing |
Roof: |
Galvanized Steel Sheet With Insulation Layer |
Core: |
Poplar,hardwood,combi,finer-joint |
Advantage: |
Anti-slip Waterproof |
Plumbing System: |
Water Pipes, Drainage Pipes, Faucets |
Drawing Design: |
Customer's Requirement |
Edges: |
All Edges Are Sealed By Waterproof Paint |
Material: |
Steel Structure With EPS/PU/Rock Wool Sandwich Panel |
Seismic Performance: |
8 Degree |
Port: |
Qingdao /Tianjing/Shanghai/Gunagzhou |
Transportation: |
Can Be Transported As A Whole Or Disassembled |
Lifespan: |
More Than 15 Years |
After Sales: |
Online Technical Support |
Design: |
Professional Architect Drawing |
Roof: |
Galvanized Steel Sheet With Insulation Layer |
Core: |
Poplar,hardwood,combi,finer-joint |
| Name | Specification | Size | Quantity | Unit |
| Form 1 | Standard container | External size: 5800mm*2500mm*2450mm Internal size: 5650mm*2350mm*2230mm Folding size: 5800mm*2500mm*400mm Weight:1.3MT |
1 | Set |
| Frame | Top girder | Special shaped steel galanize concave convex pipe 63mm*80mm*1.5mm(both sides) |
3 | Piece |
| Bottom girder | Special shaped steel galvanized concave convexpipe 63mm*160mm*2.0mm(both sides) |
3 | Piece | |
| Top beam | Galanized square pipe 50mm*50mm*1.8mm |
6 | Piece | |
| Front and rear endgirder | Special shaped steelgalvanized concave convex pipe 63mm*80mm*1.5(both sides) |
4 | Piece | |
| Sidewall frame | Special shaped steel galvanized concave convex pipe 63mm*80mm*1.5 (both sides) |
8 | Piece | |
| Bottom crossbeam | Galvanized square steel pipe 40mm*80mm*2.0mm |
4.5 | Piece | |
| Cast steel butt joint Corner Fitting |
Steel plate(200mm*100mm*15mm) | 8 | Piece | |
| Folding hinge | Galvanized hinge 85mm*115mm*3mm (Shaft column304stainless steel) |
36 | Piece | |
| Integral frame protective coating |
Cabaret high gloss enamel | 1 | Set | |
| Top of container | External roof | 104 color steel tile (0.5mm) | 6 | Set |
| Internal ceiling | 831 ceiling tile (0.326mm) | 7 | Piece | |
| Insulation rock wool | Bulk density 60kg/m3*14.5square | 14.5 | m² |
